1. In the soldering process of the PCB electronics industry, more and more manufacturers have begun to focus on selective soldering.
2. Selective soldering allows for simultaneous completion of all solder joints, reducing production costs and mitigating temperature variations encountered in reflow soldering.
3. Moreover, selective soldering accommodates sensitive components and aligns with future trends towards lead-free soldering.
4. These advantages contribute to the increasing adoption of selective soldering in various applications.
Process characteristics of selective soldering
1. The process characteristics of selective soldering can be understood by comparing it with wave soldering. The most obvious distinction lies in the fact that in wave soldering, the entire lower portion of the PCB is submerged in liquid solder, whereas in selective soldering, only specific areas come into contact with the solder wave. Due to the PCB’s poor thermal conductivity, adjacent components and board areas do not heat up enough to melt solder joints during the process. Additionally, flux must be applied prior to soldering. Unlike wave soldering where flux covers the entire PCB, in selective soldering, flux is applied only to the areas where soldering is needed, typically the underside of the PCB. Furthermore, selective soldering is suitable exclusively for through-hole components. Understanding the process and equipment specifics is essential for successful selective soldering.
2. Typical selective soldering processes include flux spraying, PCB preheating, dip soldering, and drag soldering.
3. Flux coating process: In selective soldering, the flux coating process plays a crucial role. At soldering temperatures, the flux must remain sufficiently active to prevent bridging and oxidation of the PCB. Flux spraying is achieved using an X/Y manipulator that guides the PCB through a flux nozzle, ensuring precise application onto the targeted soldering areas. Flux can be applied using single nozzles, micro-hole spray, or synchronous multi-point/pattern spray. Accuracy in flux deposition post-reflow is critical to avoid unwanted areas. Micro-sprayed flux patterns typically have a diameter greater than 2mm, with positional accuracy of ±0.5mm to ensure consistent coverage of solder joints. Flux quantity and specifications, including a recommended 100% safety tolerance range, are provided by suppliers.
4. Preheating process: In selective soldering, the primary purpose of preheating is not stress reduction but rather to pre-dry the flux, eliminating solvents and ensuring correct viscosity before encountering the solder wave. Heat from preheating minimally impacts soldering quality and is adjusted based on PCB thickness, device package specifications, and flux type. There are differing views among process engineers regarding preheating necessity: some advocate preheating before flux application, while others prefer direct soldering without preheating. Process flows can be tailored according to specific requirements.
5. Soldering process: Selective soldering employs two main methods—drag soldering and dip soldering. Selective drag soldering uses a narrow solder wave tip, suitable for tight spaces such as individual solder joints or pins on the PCB. Quality soldering results from adjusting PCB movement speed and angle over the solder wave. Tip inner diameters typically do not exceed 6mm and are optimized for various soldering needs, approached from angles ranging 0° to 12°, with a recommended tilt angle of 10° for most devices. Compared to dip soldering, drag soldering enhances heat transfer efficiency due to PCB movement across the solder wave, improving solder joint formation. Nitrogen supplied to the soldering area prevents solder wave oxidation, crucial for defect-free soldering. Modular design flexibility allows equipment adaptation to specific production needs, enhancing overall process efficiency.
6. Despite its advantages, the single-nozzle drag soldering process suffers from longer soldering times across flux spraying, preheating, and soldering stages. Efficiency challenges arise as solder joints are individually drag soldered, necessitating increased soldering time with greater joint counts. However, evolving designs incorporating multiple nozzles, such as dual-nozzle configurations, promise enhanced throughput. Dual-nozzle flux designs further optimize PCB coverage, marking a significant shift from traditional wave soldering efficiency.
