Optimizing Multilayer Board Lamination Quality: Strategies and Techniques

A. Selecting Appropriate PP and CU Foil Configuration:

  • Meeting PCB user requirements involves considering dielectric layer thickness, dielectric constant, characteristic impedance, withstand voltage, and laminate surface smoothness.
  • PP Selection Criteria:
    1. Resin capability to fill gaps in printed wires during lamination.
    2. Effective elimination of air and volatile matter between laminations.
    3. Provision of necessary dielectric layer thickness for multilayer boards.
    4. Ensuring bonding strength and a smooth appearance.
  • Recommended PP Configurations:
    • For 4-layer laminates: 7628, 7630, or 7628+1080, 7628+2116.
    • For >6 layers: Mainly 1080 or 2116, with 7628 for increased dielectric layer thickness.
    • Symmetrical PP placement for mirror effect and prevention of plate bending.
  • CU Foil Quality:
    • Configured based on PCB user requirements, adhering to IPC standards.

B. Inner Core Board Processing Technology:

  • Inner core board treatment involves black oxidation and browning processes.
  • Black Oxidation Treatment:
    • Forms a black oxide film on inner copper foil.
    • Thickness of the black oxide film: 0.25-4.50mg/cm2.
  • Browning Process (Horizontal Browning):
    • Forms an organic film on inner copper foil.
  • Functions of Treatment Process:
    1. Increases contact surface between inner copper foil and resin, enhancing bonding force.
    2. Improves effective wettability of molten resin to copper foil.
    3. Prevents decomposition of curing agent dicyandiamide in liquid resin at high temperatures.
    4. Enhances acid resistance during wet processes, preventing pink circles.

This comprehensive approach outlines key strategies for improving multilayer board lamination quality, addressing material selection and inner core board processing techniques.
