About FPC Hollow Board

The FPC hollow board, also known as the window circuit board, is a specialized type of flexible printed circuit board (FPC) that is characterized by areas that are “hollowed out” or etched. This board is manufactured using processes such as punching, etching, and lithography.

It is constructed from high-performance materials such as polyimide or polyester film, offering superior flexibility, reliability, and durability. The FPC hollow board boasts several key features: high wiring density, lightweight design, thin profile, and exceptional bending properties, making it an ideal solution for space-constrained and flexible electronic applications.

Commonly used in mobile phones, computer components, LCD screens, and CD players, the FPC hollow board has gained widespread adoption in various high-tech industries. However, like all technologies, it does have certain limitations. The production process is complex and requires multiple steps, which extends production time. Moreover, with the rapid advancements in electronic technologies—particularly the widespread adoption of large-scale integrated circuits (LSIs)—there is a growing demand for even smaller, more intricate features, which poses challenges for the high-density routing of FPC hollow boards.

The through-holes in flexible printed circuit boards can also be drilled using numerical control (CNC), similar to rigid PCBs. However, FPC hollow boards are less suited to the drilling of coil double-sided metallized holes. As circuit density increases and hole diameters decrease, conventional CNC drilling methods may reach their limits. To address these challenges, newer drilling technologies such as plasma etching, laser drilling, and chemical etching have been developed and are now being implemented. These advanced techniques are more suitable for the high-precision drilling required in high-density flexible circuits.

Advantages and Disadvantages of FPC Hollow Board

The FPC hollow board, a versatile product of flexible printed circuit technology, is made using high-quality polyimide or polyester film and other reliable materials. It offers remarkable flexibility, durability, and high performance, with features such as:

• High wiring density
• Thin profile
• Lightweight design
• Excellent bending performance

These characteristics make it highly suitable for a variety of applications, including mobile devices, computers, LCD displays, and more. However, it is important to acknowledge the inherent challenges associated with this technology:

• The production process is complex and involves multiple stages, leading to longer lead times.
• As electronic technology evolves, particularly with the growing use of large-scale integrated circuits (LSI), the demand for increasingly fine lines and high-density routing is putting pressure on the current capabilities of FPC hollow boards.

Despite these challenges, the FPC hollow board remains a practical and cost-effective solution for many applications. With ongoing advancements in technology, FPC hollow boards are expected to become even thinner, more flexible, and capable of withstanding even more bending cycles. Additionally, as manufacturing techniques improve, the cost of production will decrease, making these boards more accessible. The future of FPC hollow boards looks promising, with continued innovation set to meet the evolving needs of the electronics industry.
