Quality Control Points of PCBA SMT Assembly
1. SMT Assembly Process
The systematic quality control of solder paste printing and reflow soldering temperature control are critical elements in the SMT chip processing phase of PCBA manufacturing. For high-precision circuit boards with specialized or complex processes, laser-cut stencils should be used according to specific requirements to ensure higher quality and process accuracy. Depending on the PCB design specifications and the customer’s product needs, modifications such as adding U-shaped holes or reducing mesh holes in the stencil may be necessary. The stencil design should be tailored to meet the demands of the PCBA processing technology.
Among these factors, precise temperature control in the reflow oven plays a crucial role in ensuring proper solder paste wetting and secure stencil soldering. Temperature settings should follow standard operating procedures (SOP) to ensure optimal results and minimize quality defects during the SMT assembly process.
Additionally, strict adherence to AOI (Automated Optical Inspection) testing is essential for reducing defects caused by human error.
**Two, DIP Plug-in Post Soldering**
DIP plug-in post soldering is the most critical and final step in the PCB manufacturing process. During this stage, the choice and use of the furnace fixture for wave soldering play a crucial role. The key challenge is how to utilize the furnace fixture to significantly improve yield rates, reduce soldering defects such as continuous solder, insufficient solder, and solder shortages, while also meeting the varying customer requirements for process upgrades.
**Three, Test and Program Firing**
The manufacturability report is an essential evaluation that should be conducted before starting full production, once the customer’s production contract is received. In the earlier DFM report, we can provide the customer with suggestions for PCB design improvements, such as adding key test points (test pads) for assessing continuity and connectivity after PCB soldering and subsequent PCBA assembly. When feasible, communication with the customer about providing the backend program is beneficial. The program can then be burned into the core master IC using a programmer. This enables more streamlined testing of the circuit board via manual intervention, ensuring the overall integrity of the PCBA is verified and defective products can be identified promptly.
**Four, PCBA Manufacturing Test**
Additionally, many customers seeking one-stop PCBA processing services require comprehensive back-end testing for their PCBA assemblies. These tests typically include ICT (In-Circuit Testing), FCT (Functional Testing), burn-in testing (aging test), temperature and humidity testing, drop testing, and others.
The four points outlined above represent key aspects that require careful attention during PCBA surface mount processing. These are also the main topics shared by the Manchester United Electronics Editor in today’s overview.
If you have any PCB manufacturing needs, please do not hesitate to contact me.Contact me
