With the rapid advancement of the electronics industry, PCB (Printed Circuit Board) design and manufacturing processes have become increasingly sophisticated. One common technique employed by PCB manufacturers for graphic transfer is the use of dry film, which has gained popularity due to its efficiency. However, throughout my experience in after-sales service, I have encountered numerous challenges and misunderstandings from customers when using dry film. These issues are often repeated, so I have compiled them here for clarity and reference.
### 1. Holes in the Dry Film Mask
A frequent concern from customers is the appearance of holes in the dry film mask. Many believe that increasing the temperature and pressure during the bonding process will enhance adhesion and prevent holes from forming. However, this approach is misguided. When temperature and pressure are excessively raised, the solvent in the resist layer tends to evaporate more quickly. This excessive evaporation leads to dryness, causing the film to become brittle and thinner, making it more prone to breaking during the development process. The key to addressing this issue is to preserve the toughness and flexibility of the dry film throughout the process.
### Recommended Solutions:
1. **Lower the Temperature and Pressure**: Reducing the temperature and pressure during bonding helps prevent the excessive evaporation of solvents, maintaining the integrity of the dry film and reducing the risk of holes.
2. **Optimize the Exposure Process**: Ensure that the exposure time and intensity are carefully controlled to avoid overstressing the film during the photolithography process.
3. **Use Proper Film Handling**: When handling dry film, make sure that it is stored and applied under optimal conditions to prevent unnecessary physical stress that could cause holes to form.
By understanding and addressing these factors, manufacturers can improve the longevity and reliability of the dry film, resulting in higher quality PCB production.
### Optimizing Dry Film Process in PCB Manufacturing
The dry film process plays a critical role in ensuring high-quality PCB production. To achieve consistent results and avoid common defects like seepage plating or poor adhesion, several factors must be carefully controlled. Below are key points that can enhance the dry film process, specifically focusing on drilling, exposure, development, and electroplating.
#### 1. Improving Drilling and Piercing
To improve drilling and piercing during PCB fabrication, it’s essential to maintain precise parameters. Using sharp, high-quality drill bits and optimizing drilling speeds can reduce material stress and improve hole quality. Additionally, ensuring that the drilling pressure is controlled prevents damage to the copper layer and avoids issues like hole wall delamination.
#### 2. Increasing Exposure Energy
Proper exposure energy is crucial in the dry film process. Exposure energy should be carefully calibrated to avoid both under- and over-exposure. Under-exposure leads to incomplete polymerization, resulting in softening and swelling of the film during development. This may cause the film to peel off or result in unclear patterns. Over-exposure, on the other hand, can make development difficult and lead to issues during electroplating, such as warping or peeling of the film. Therefore, controlling exposure energy ensures consistent polymerization and solid adhesion to the copper substrate.
#### 3. Reducing Development Pressure
Development pressure should be minimized during the PCB process. Excessive pressure during development can cause the semi-fluid dry film to deform, leading to irregularities in the final image quality. It’s essential to apply a gentle, consistent pressure to ensure the film maintains its integrity and sharpness.
#### 4. Limiting Film Parking Time
Once the film is applied, the parking time should be kept to a minimum before further processing. Prolonged exposure to air or waiting too long before processing can cause the semi-fluid film at the corners to spread or thin due to pressure. This results in uneven patterns and poor adhesion during subsequent steps.
#### 5. Avoiding Over-stretching During Pasting
During the dry film pasting process, it is essential to avoid stretching the film too tightly. Excessive tension during pasting can lead to micro-tears, warping, or inconsistencies in the film’s thickness, which will affect the overall adhesion to the copper board. A steady, controlled application ensures the film adheres properly without risking damage.
### Seepage Plating During Dry Film Electroplating
Seepage plating is a common issue in PCB production, particularly when the dry film does not adhere properly to the copper-clad board. This results in the plating solution infiltrating the “negative phase” areas of the coating, making the plating layer thicker than intended. To avoid this problem, several factors should be considered:
#### 1. Exposure Energy
As discussed, exposure energy plays a vital role in the dry film’s polymerization process. If the exposure energy is too low, incomplete polymerization will lead to swelling and softening of the resist film during development, which weakens adhesion between the dry film and the copper surface. Conversely, over-exposure leads to a hard, overly polymerized resist film, which makes it difficult to develop and can cause issues such as warping or peeling during electroplating. Proper exposure control is critical for avoiding seepage plating.
#### 2. Film Temperature
The temperature of the film also affects its bonding strength. If the film temperature is too low, the resist may not soften adequately, leading to poor adhesion between the dry film and the copper substrate. On the other hand, if the temperature is too high, the solvents within the resist will evaporate too quickly, causing the film to become brittle. This can result in the resist warping or peeling off during electroplating, leading to seepage plating. Maintaining the appropriate temperature ensures proper film flow and adhesion.
#### 3. Film Pressure
The pressure applied during the pasting of the dry film must be balanced. Too low a pressure can create gaps or uneven film coverage, resulting in poor adhesion between the film and the copper surface. High pressure, however, can cause excessive volatilization of the solvents, making the resist brittle and prone to peeling during electroplating. Finding the optimal film pressure is essential for ensuring consistent film quality and preventing seepage plating.
### Conclusion
Effective control of the dry film process is critical for avoiding defects such as seepage plating, poor adhesion, or warping. By optimizing exposure energy, development pressure, film temperature, and pasting techniques, PCB manufacturers can significantly improve the quality and reliability of their products. A disciplined approach to these variables ensures a high-quality bond between the dry film and the copper-clad board, leading to better overall performance in the electroplating process and the final PCB.
