**Points to Note in PCB Anti-Deformation Design**
1. **What is PCB Deformation?**
PCB deformation, commonly referred to as warpage, significantly impacts soldering and functionality. This is particularly critical for communication products where single boards fit into sub-boxes with standard spacing. As panel sizes decrease, the gap between adjacent components narrows. If a PCB warps, it can disrupt the electronic processing during insertion and removal, potentially damaging components. Furthermore, PCB deformation severely affects the reliability of BGA components. Thus, controlling PCB deformation during and after the soldering process is crucial.
2. **PCB Anti-Deformation Design Requirements**
(1) The extent of PCB deformation is directly related to its size and thickness. Typically, the aspect ratio should be less than or equal to 2, and the width-to-thickness ratio should be no greater than 150.
(2) Multilayer rigid PCBs consist of copper foil, prepreg, and core material. To minimize deformation after pressing, the laminated structure must adhere to symmetrical design principles, ensuring that the thickness of the copper foil, the type and thickness of the medium, the distribution of graphics (circuit layers, plane layers), and pressing properties are symmetrical around the PCB’s centerline.
(3) For larger PCBs, anti-deformation stiffeners or backing boards (often referred to as fire-proof boards) should be incorporated. This serves as a mechanical reinforcement method.
(4) For structural components that may induce PCB deformation, such as CPU card holders, a backing plate should be designed to mitigate this risk.
