The PCBA board processing and baking method:
Large-scale PCBs are typically laid flat with up to 30 pieces stacked. Remove the PCB from the oven within 10 minutes after baking and allow it to cool naturally at room temperature.
Small and medium-sized PCBs are mostly laid flat, with stacks of over 40 pieces; upright stacking is also permissible. Remove PCBs from the oven within 10 minutes of baking. Components that are no longer needed after repair do not require baking.
PCBA baking requirements:
Regularly check if the material storage environment meets specified conditions. Personnel on duty must undergo training. Notify relevant technical personnel promptly of any abnormalities during the baking process. Take anti-static and heat insulation measures when handling materials. Store and bake leaded and lead-free materials separately. After baking, cool to room temperature before proceeding with assembly or packaging.
The PCBA board is integral to most electrical equipment, facilitating a variety of functions with its densely packed power electronic devices. Central to the PCBA board is the baking process. What steps are involved in processing the PCBA board during baking? What are the common issues? Let’s delve into the “baking steps and common conditions of PCBA board processing.”
Before PCBA processing, there is a critical step often overlooked by many manufacturers—pre-baking the boards. This pre-baking process is essential as it removes moisture from both the PCB and its components. By reaching a specified temperature, typically 120 ± 5 degrees Celsius, the pre-baking ensures optimal conditions for flux adhesion to the components and pads, significantly improving soldering effectiveness. Let me guide you through the pre-baking process in PCBA manufacturing.
PCBA board pre-baking requirements are as follows: maintain a temperature of 120 ± 5 degrees Celsius for approximately 2 hours, starting the timer once the oven reaches the specified baking temperature. For precise parameters, refer to the corresponding PCB pre-baking specifications.
Temperature and duration settings for pre-baking vary based on the PCB’s age since manufacture:
– For PCBs sealed and unpacked within 2 months, bake at 120 ± 5 degrees Celsius for 1 hour.
– PCBs aged between 2 to 6 months require baking for 2 hours at the same temperature.
– PCBs older than 6 months up to 1 year should be baked for 4 hours at 120 ± 5 degrees Celsius.
– After baking, PCBs must be processed within 5 days. Unprocessed boards should undergo another hour of pre-baking before use.
– PCBs older than 1 year require a 4-hour bake at 120 ± 5 degrees Celsius followed by re-tinning for usability.
Flux quality directly influences soldering during PCBA processing and assembly. What are the common defects encountered during soldering, and how can these issues be analyzed and improved? Excessive residue on the PCB surface post-soldering is a common issue, usually stemming from inadequate pre-heating or insufficient tin furnace temperatures, excessively fast board speeds, or the use of excess flux or improper component-to-hole ratio causing flux accumulation. Furthermore, prolonged use of flux without proper thinning can exacerbate these issues. Awareness of these points is crucial for problem prevention.
Another critical issue is the risk of fire during operations, demanding special attention. Factors such as the absence of an air knife in the wave soldering furnace leading to flux accumulation and drips onto heating elements, incorrect air knife angles causing uneven flux distribution, excessive glue resulting in ignition, and improper board travel speeds contributing to inadequate flux volatilization are common culprits. Process-related factors, such as inappropriate PCBA sheet handling or proximity to heating elements, can also exacerbate these risks.
Corrosion, indicated by green components or black solder joints, is another prevalent defect resulting from insufficient pre-heating, which leaves harmful flux residues. Neglecting to clean flux after soldering exacerbates these issues. Understanding these factors can significantly enhance PCBA processing and soldering quality.
The performance of flux directly impacts soldering quality during PCBA processing. What are the typical issues encountered? Poor connections or leakage due to inadequate insulation are often related to flawed PCBA board designs. Shenzhen Huatao Intelligent Technology Co., Ltd. specializes in professional PCBA board design.
Poor-quality PCB solder masks prone to conducting electricity can lead to soldering issues such as false, continuous, or missed solder joints, uneven flux coating, severe oxidation of pads or solder joints, flawed PCB layouts, uneven foam solder, and improper hand-tinning practices. Adjusting flux types or ensuring proper solder quality can resolve issues with overly bright or dull solder joints.
Precautions during PCBA board baking include wearing heat-insulating gloves when handling hot PCBs and strictly controlling baking times to prevent over- or under-baking. Allow baked PCBs to cool to room temperature before use. These measures ensure optimal PCBA manufacturing processes and product quality.
