1. During PCB manufacturing, the substrate undergoes multiple exposures to heat and various chemicals. For instance, after etching, the substrate must be washed with water, dried, heated, and subjected to hot electroplating during the pattern electroplating process.
2. After the application of the green solder mask and the printing of logos or characters, the substrate needs to be either heated or UV-cured. Additionally, when hot air is applied for tin spraying, the substrate experiences significant thermal shock. These steps can lead to PCB warping.
3. To prevent warping, it is essential to avoid improper circuit design or incorrect processing techniques during PCB production.
1. For example, the conductive circuit pattern on the PCB may be unbalanced, or the circuits on both sides of the PCB board could be noticeably asymmetrical. A large area of copper on one side can create significant stress, leading to PCB warping. Additionally, high processing temperatures or thermal impacts during PCB manufacturing can also cause the board to warp.
2. Regarding the impact caused by improper storage of substrates, PCB manufacturers should address this issue by improving the storage environment. Ensuring that substrates are stored horizontally and avoiding heavy pressure is sufficient to prevent warping. For PCBs with large copper areas in the circuit pattern, it is advisable to use mesh copper foil to reduce stress.
3. Copper foil: A cathodic electrolytic material, copper foil is a thin, continuous metal layer deposited onto the base layer of the circuit board, serving as the conductor for the PCB. It adheres easily to the insulating layer, accepts the printed protective layer, and forms a circuit pattern after corrosion.
4. Copper mirror test: This is a flux corrosion test that uses a vacuum deposition film on a glass plate.
5. Copper foil is made of copper, with a specific proportion of other metals. Copper foil typically comes in two grades: 90 foil and 88 foil, where the copper content is 90% and 88%, respectively. The standard size is 16*16 cm. Copper foil is widely used in decorative applications, including hotels, temples, Buddha statues, golden signage, tile mosaics, and handicrafts.
6. Copper foil has low surface oxygen content, allowing it to bond well with various substrates, such as metals and insulating materials, and it performs well across a wide temperature range. It is primarily used for electromagnetic shielding and anti-static applications. The conductive copper foil is applied to the surface of a substrate and bonded with the metal base material, providing excellent conductivity and an effective electromagnetic shielding effect. Copper foil can be categorized into self-adhesive, double-conducting, and single-conducting types.
7. Electronic-grade copper foil (with purity above 99.7% and thickness ranging from 5µm to 105µm) is a fundamental material in the electronics industry. With the rapid growth of the electronic information industry, the demand for electronic-grade copper foil is increasing. It is widely used in industrial calculators, communication equipment, QA equipment, lithium-ion batteries, consumer electronics such as televisions, video recorders, CD players, photocopiers, telephones, air conditioners, automotive components, gaming consoles, and more. Both domestic and international markets have growing demand for electronic-grade copper foil, particularly high-performance variants. Industry projections indicate that by 2015, China’s domestic demand for electronic-grade copper foil will reach 300,000 tons, positioning China as the world’s largest manufacturing hub for printed circuit boards and copper foils. The market for high-performance electronic-grade copper foil remains promising.
8. Industrial copper foil can be broadly categorized into two types: rolled copper foil (RA copper foil) and electrodeposited copper foil (ED copper foil). Rolled copper foil offers superior ductility and is commonly used in the early stages of flexible board manufacturing. Electrolytic copper foil, on the other hand, is more cost-effective to produce compared to rolled copper foil. Since rolled copper foil is a crucial raw material for flexible boards, any advancements in the properties or price fluctuations of rolled copper foil have a significant impact on the flexible board industry.
