What are the commonly used types of PCBA substrates?
1. The FR-4 board is an epoxy-based material known for its high mechanical and dielectric properties, as well as its excellent heat and moisture resistance. Additionally, it offers good machinability.
2. The aluminum substrate is a metal-based copper-clad laminate that provides effective heat dissipation. Typically, it consists of a three-layer structure: a circuit layer (copper foil), an insulating layer, and a metal base layer. Aluminum substrates are frequently used in LED lighting applications. One side features a white coating for soldering LED pins, while the reverse side retains the natural color of aluminum. Generally, thermal conductive paste is applied to enhance contact with the heat-generating components of the PCB.
3. The FPC board is constructed from polyimide or polyester film, offering high reliability and exceptional flexibility. It features high wiring density, lightweight design, thin thickness, and excellent bendability. This makes it ideal for high-end products such as mobile phones and hard disk drives.
PCBA serves as the cornerstone of electronic products, akin to the strategic role of the Chinese military in a tri-army confrontation. The reliability, usability, and stability of products are closely tied to the quality of PCBA. Consequently, during the procurement of PCBA, it is essential to prioritize quality control measures. This involves employing a professional perspective to assess whether each PCBA board meets the application requirements of electronic devices.
1. The reliability of component soldering on the PCBA. The durability of the PCB circuit board and its component soldering directly influences the performance of electronic products during operation. Over time, circuit boards can be subjected to oxidation, thermal radiation, drops, and extreme loading conditions, which may lead to soldering issues on what was initially a functioning PCBA when it left the factory, ultimately resulting in product failure. Additionally, the choice to utilize original brand components in the PCBA process is critical for ensuring electronic product quality. Many second-hand or counterfeit components may fail or even explode after prolonged use. The same holds true for PCB circuit boards. Depending on the product’s application environment, considerations must be made to prevent PCB deformation and mitigate thermal effects. These factors should be addressed during the PCBA procurement process, alongside rigorous testing.
2. PCBA aging test performance report. In high-volume production, rigorous aging tests are essential for evaluating the stability and reliability of PCBA boards under strict conditions. Many companies forgo this step to cut costs, which can lead to defects in batches of products delivered to customers. This oversight can result in significant losses. Therefore, when acquiring PCBA, it is advisable to request aging test requirements for large orders, set up aging test fixtures, and require suppliers to furnish aging test performance reports.
3. Management of the PCBA assembly process. The assembly process for PCBA boards, enclosures, and packaging is equally important. Improper handling during assembly can damage soldered components on tested PCBA boards, leading to defects post-assembly. It is crucial that PCBA suppliers adhere to strict operational guidelines during the assembly process, ensuring that workers are supervised to complete procedures correctly.
If you have any PCB manufacturing needs, please do not hesitate to contact me.Contact me
