Introduction to PCB Distortion in PCBA Mass Production:

  • PCB distortion in mass production can significantly impact patching and testing, necessitating avoidance measures.

2. Causes of PCB Distortion:

  • Raw Material Selection:
    • Low T value, especially in paper-based PCBs, can lead to bending due to high processing temperatures.
  • Unreasonable PCB Design:
    • Uneven component distribution and larger connectors induce excessive thermal stress, causing permanent distortion.
  • Design Issues:
    • Double-sided PCBs with uneven copper foil distribution may result in uneven shrinkage and deformation.
  • Fixture Problems:
    • Improper fixture use, especially tight clamps in wave soldering, can lead to PCB expansion and deformation.
  • Reflow Soldering Temperature:
    • Excessive temperatures during reflow soldering contribute to PCB distortion.

3. Solutions Proposed by Engineers:

  • Material Selection:
    • Opt for PCBs with high Tg or increase thickness for an optimal aspect ratio if cost and space permit.
  • Balanced PCB Design:
    • Ensure balanced steel foil area on both sides, cover unused areas with copper in a grid pattern to enhance PCB rigidity.
  • Pre-Bake PCB:
    • Pre-bake PCBs before patching at 125℃/4h to minimize distortion risks.
  • Fixture Adjustment:
    • Adjust fixtures and clamping distances to accommodate PCB thermal expansion space.
  • Temperature Control in Soldering:
    • Lower soldering process temperatures, and if slight distortion occurs, use positioning fixtures and heat reset to release stress.

4. Conclusion:

  • Engineers propose practical solutions to address PCB distortion issues during PCBA processing, emphasizing material selection, balanced design, pre-baking, fixture adjustments, and temperature control for satisfactory results.
