**How Does Moisture Cause Significant Issues on Printed Circuit Boards?**
Moisture, present in the epoxy glass prepreg, diffuses into the PCB during storage. When absorbed, it can lead to various defects in the PCB assembly. The wet process time during PCB manufacturing can result in microcracks or create pockets of moisture within the resin interface. As high temperature and vapor pressure correlate with the lead-free assembly process, they contribute to moisture absorption.
Adhesive and cohesive failures in printed circuit boards can lead to delamination or cracking, and moisture can facilitate metal migration, creating low impedance paths that affect dimensional stability. A reduction in the glass transition temperature, along with an increase in the dielectric constant and other technical issues, can slow down circuit switching speeds and heighten propagation time delays.
The primary impact of moisture on PCBs is the degradation of metallization, lamination, solder mask integrity, and the overall manufacturing process. Moisture’s influence can lead to excessive thermal stress as the glass transition temperature decreases, sometimes resulting in severe short circuits due to moisture ingress and subsequent ion corrosion. Other common issues related to moisture absorption in PCB assemblies include compromised flame retardancy, delamination, increased dissipation factor (DF), elevated dielectric constant (DK), thermal stress on plated through holes, and copper oxidation.
**Methods to Mitigate Moisture in PCB Manufacturing:**
Whether utilizing simple or complex technologies, many PCB engineering processes require wet procedures and the removal of residual moisture. The raw materials used in PCB manufacturing must be safeguarded during storage, handling, and assembly stresses. Here is a concise guide for implementing controls at various stages of PCB operations:
1. **Lamination**
Lamination serves as a dehydration step in PCB manufacturing, as the core and prepreg are stacked to bond the layers into a laminate. Key factors to control during lamination include temperature, duration, and heating rate. In instances of low dryness, lowering the vacuum can help minimize the attraction of internal voids for moisture absorption. Therefore, using gloves when handling prepregs effectively controls moisture levels and reduces cross-contamination. A non-corrosive humidity indicator card should be flexible to monitor humidity levels as necessary. Laminates should undergo a short washing cycle and be stored in a controlled environment to prevent moisture pockets from forming.
2. **Post-Lamination Process and PCB Assembly**
Following drilling, photographic imaging, and etching operations, the moisture absorption rate during the wet process increases. Screen printing curing and solder mask baking are critical steps for relieving entrained moisture. Minimizing the time between processes and carefully managing storage conditions is more effective in reducing moisture levels. Ensuring that the PCB is sufficiently dry during the early stages of lamination helps reduce the need for extended baking after lamination. Additionally, employing high-quality surface treatments prevents cracking during drilling, and moisture residue should be eliminated by baking prior to hot-air solder leveling. The baking duration should be adjusted based on moisture content, the complexity of PCB manufacturing, surface treatment quality, and the required thickness of the circuit board.
In conclusion, understanding the current effects of moisture in PCB manufacturing is vital to prevent failures, damage, and short circuits, while also minimizing rework costs. Researchers are actively pursuing more advanced solutions by leveraging environmentally friendly PCB technologies to control moisture at every stage of manufacturing, ultimately saving time, energy, and costs.
